1. AND-C intelligent control system

The cage intelligent control subsystem is the center of the AND cage intelligent system. It is composed of Central Processor and various functional modules to complete the control of various functions inside the cage and the intelligent integration with the external systems and equipment of the cage. Under the control system, the safe acquisition and distribution of power supply is realized, the cage door is opened and closed according to the set program, and the internal functions such as intelligent wheel finding, emergency communication, and hazard identification of the cage are intelligently controlled. At the same time, it is integrated into the driving system and external equipment to realize intelligent control.

2. AND-E wireless charging system

Adopt long-distance high-power wireless charging method, non-contact, no spark, adaptive control, automatic charging in place, automatic power failure when leaving, epoxy resin pouring seal, high strength, waterproof and anti-smashing, equipped with large-capacity batteries, with constant current Charging, constant voltage charging, trickle charging and other modes, complete protection, convenient installation and maintenance-free.

Lithium battery application site

3. AND-D type automatic cage door

It is locked in conjunction with the cage position and the operating vehicle, and realizes the automatic opening and closing of the cage door curtain with one button, which is safe and efficient, and reduces the labor intensity.

Automatic cage door application site

4. Intelligent minecart locker in the cage

(1) AND-ZB intelligent minecart lock machine

AND-ZB type intelligent minecart locking machine is installed on both sides of the track in the cage, which completes damping parking and minecart centering without gap. It can adapt to the change of the number and wheelbase of minecarts, and is linked with the cage position and the operating system to realize the cage.

AND-ZB intelligent minecart lock machine application site

(2) AND-W type rubber wheel minecart intelligent locking device

AND-W type cage rubber wheel minecart intelligent locking device is installed in the middle or both sides of the cage, remote control/automatic operation, the minecart locking device automatically adapts to the change of the vehicle wheelbase, vehicle finding and positioning, limits the force to wedge tightly, reliably blocks the wheels, and avoids vehicle displacement. It is linked with the cage position and the operating system to realize the automation of vehicle blocking.

Application site of rubber wheel minecart locking in cage
